Scheepskabel

RFA-FRHF(i)+WSR/WJR 250V

DownloadDatasheet PDF RFA-FRHF(i)+WSR/WJR 250V Fire Resistant + Water Spray Resistant and/or Water Jet Resistant collectively and individually screened instrumentation and... read more

Beschrijving

Download
Datasheet PDF

RFA-FRHF(i)+WSR/WJR 250V

Fire Resistant + Water Spray Resistant and/or Water Jet Resistant collectively and individually screened instrumentation and communication cable 250 V

Application: For fixed installation in most areas and on open deck in ships and off shore units. Especially intended to ensure the availability of all critical transportation-, comfort- and safety systems, i.e. to meet the concepts of; Orderly Evacuation (3 hours burning time) and Safe Return to Port (Fire test with simultaneous Water Spray / Water Jet + mechanical shocks) to simulate the firefighting conditions.
If the cable is exposed to direct sunlight, we recommend cable with black outer sheath or a protective covering.

Main characteristics
Rated voltage 150/250V (300V)
Halogen-free IEC 60754 series
Flame-retardant IEC 60332-1-2 -test for single insulated wire and cable
IEC 60332-3-22 -test for bunched wires and cables, category A
Smoke emission IEC 61034 series
Fire- and Water Spray Resistant IEC 60331-2 (180 min test) + EN 50200:2015 Annex E (diameter ≤ 20 mm)
Fire- and Water Jet Resistant IEC 60331-1 (180 min test) + BS 8491:2008 (diameter > 20 mm)
Oil resistance (only SHF2) IEC 60811-404 conditions according to 60092-360/SHF2
For details see general information section
Electrical data: 0,75mm2 1,5mm2 Unit
Loop resistance of pair, max. / +20°C 52 24,4 ohm/km
Pair capacitance, nom. / 1 KHz 55 75 nF/km
Loop inductance, nom. 0,6 0,7 mH/km
Insulation resistance / +20°C ≥1500 ≥1500 Mohm/km
Recommended minimum bending radius (fixed installation): 4 x outer diameter of the cable
Temperature rating: Maximum conductor temperature + 90 °C
Fixed installation -40 °C to +80 °C
Minimum recommended installation temperature -15 °C
For details see general information section



Part number Number of conductors & cross-section
n x mm2
Nominal outer diameter
mm
Approximate weight
kg/km
Min. bending radius fixed installation
mm
620664 1x2x0,75 8,5 80 50
620666 2x2x0,75 Quad 9,5 110 55
620667 2x2x0,75 13,0 155 80
620669 4x2x0,75 15,5 235 90
620671 7x2x0,75 18,5 365 110
620673 8x2x0,75 20,0 415 120
620675 10x2x0,75 23,0 525 140
620677 12x2x0,75 24,0 600 145
620679 14x2x0,75 25,5 680 155
620681 16x2x0,75 27,5 775 165
620683 19x2x0,75 29,5 895 175
620685 24x2x0,75 33,5 1135 200
620686 30x2x0,75 37,0 1390 220
621550 1x2x1,5 9,0 105 55
621552 2x2x1,5 Quad 11,0 170 65
621553 2x2x1,5 14,5 230 90
621555 4x2x1,5 17,5 345 105
621557 7x2x1,5 21,0 545 125
621559 8x2x1,5 23,0 635 135
621561 10x2x1,5 26,5 800 160
621563 12x2x1,5 27,5 920 165
621565 14x2x1,5 29,5 1050 175
621567 16x2x1,5 31,5 1205 190
621569 19x2x1,5 34,0 1415 205

Other sizes on request.

Part number for oil resistant SHF2 cable:
4 + code from above table ➞ 4xxxxxxxxxx
