RFOU MV

Offshore power medium voltage

MEDIUM VOLTAGE 3,6/6kV, 6/10kV, 8,7/15kV, 12/20kV, 18/30kV
Based on: IEC 60092-354 / NEK TS 606



DESIGN

Conductor
Class 2 conductor (class 5 on request) tinned copper, based on IEC 60228 (class 5 also available upon request).

Semiconducting
Semiconducting halogen free compound

Insulation
Halogen Free Ethylene propylene, type EPR according to IEC 60092-351.

Insulation screen
Semiconducting halogen free compound + tinned copper wire braid.
The standard identification is the following:
1 conductor ……………………. Natural
3 conductors ……………………off-white + black + red (other colors available as option)
Each pair is numbered.
3 x ……………………. brown (for triads)

Inner Sheath

Halogen Free compound.

Braid / Armour
Tinned copper wires braid.

Outer sheath
Mud resistant thermosetting compound, red colour, low smoke and halogen free, type SHF MUD.

DESIGNATION
P2/P9: 3,6/6kV. P3/P10: 6/10kV. P4/P11: 8,7/15kV. P19/P21:12/20kV. P20/P22:18/30kV

APPLICATIONS
Offshore power Medium Voltage cables. Medium voltage heavy duty, mud resistant cables for offshore applications. Halogen free, flame and fire non propagator. Excellent resistan-ce to oils, abrasion, petrochemical fluids, moisture and salt water. Based on IEC 60092-354 and NEK TS 606. Suitable for fixed installations in vessels and oil rigs.
