BFOU P5/P12

Fire resistant offshore power 0,6/1kV

LOW VOLTAGE 0,6/1 kV
Based on: IEC 60092-353 / NEK TS 606



DESIGN
Conductor
Flexible conductor tinned copper, based on IEC 60228.

Insulation

Mica tape + Halogen Free Ethylene propylene, type EPR according to IEC 60092-351. The standard identification is the following:
1 conductor ……………………. natural
2 conductors ……………………. blue + brown
3 conductors ……………………. brown + black + grey
4 conductors ……………………. brown + black + grey + blue
5 or more conductors ……….white numbered.

Screen

Individual polyester/copper tape with tinned copper drain wire.

Bedding

Halogen Free compound.

Braid / Armour

Tinned copper wire braid.

Outer sheath

Mud resistant thermosetting compound, black colour, low smoke and halogen free, type SHF MUD.



APPLICATIONS
Fire resistant offshore power 0,6/1kV cables. These fire resistant cables are specially de-signed to transmit electric power in the presence of fire, assuring electric supply to emer-gency circuits, like signaling lights, smoke extractors, acustic alarms, water pumps, etc. In case of fire, they do not emit toxic or corrosive gases, thereby protecting public health and avoiding any possible damage to electronic equipment. They are also heavy duty, mud resistant cables for Offshore applications.Halogen free, flame and fire non propagator. Excellent resistance to oils, abrasion, petrochemical fluids, moisture and salt water. Ba-sed on IEC 60092-353 and NEK TS 606. Suitable for fixed installations in vessels and oil rigs, assuring the highest level of safety, security and reliability.

For further technical data please request this cable’s technical datasheet.
