LKSM-FRHF+WSR/WJR

Fire Resistant + Water Spray Resistant and/or Water Jet Resistant, armoured power and control cable 0,6/1kV

Application: For fixed installation in most areas and on open deck in ships and off shore units. Especially intended to ensure the availability of all critical transportation-, comfort- and safety systems, i.e. to meet the concepts of; Orderly Evacuation (3 hours burning time) and Safe Return to Port (Fire test with simultaneous Water Spray / Water Jet + mechanical shocks) to simulate the fi refi ghting conditions.
If the cable is exposed to direct sunlight, we recommend cable with black outer sheath or a protective covering.

Main characteristics
Rated voltage AC 0,6/1kV (1,2kV)
DC 0,9/1,5kV (if voltage to earth does not exceed 0,9kV)
Halogen-free IEC 60754 series
Flame-retardant IEC 60332-1-2 -test for single insulated wire and cable
IEC 60332-3-22 -test for bunched wires and cables, category A
Smoke emission IEC 61034 series
Fire- and Water Spray Resistant IEC 60331-2 (180 min test) + EN 50200:2015 Annex E (diameter ≤ 20 mm)
Fire- and Water Jet Resistant IEC 60331-1 (180 min test) + BS 8491:2008 (diameter > 20 mm)
Oil resistance (only SHF2) IEC 60811-404 conditions according to 60092-360/SHF2
Recommended minimum bending radius (fixed installation): 4 x outer diameter of the cable
Temperature rating: Maximum conductor temperature + 90 °C
Fixed installation -40 °C to +80 °C
Minimum recommended installation temperature -15 °C
For details see general information section



Part number
Normal

G-type
Number of conductors & cross-section
n x mm2
Cross-section of armour
mm2
Nominal outer diameter
mm
Approximate weight
kg/km
Current Rating A
at +45°C
Min. bending radius fixed installation
mm
628541 1×1,0 3,0 6,5 75 18 40
628568 1×1,5 3,0 7,0 85 23 40
628570 1×2,5 3,1 7,5 95 30 45
628572 1×4 3,1 8,0 115 40 50
628574 1×6 3,1 8,5 145 52 50
628576 1×10 3,5 10,0 205 72 60
629060 627058 1×16 Flex 4,0 11,0 265 94 65
629061 627060 1×25 Flex 4,9 13,0 380 123 80
629062 627062 1×35 Flex 5,5 14,0 480 153 85
629063 627064 1×50 Flex 8,7 16,5 670 196 100
629064 627066 1×70 Flex 10,0 18,5 905 240 110
629065 627068 1×95 Flex 11,5 20,0 1140 284 120
629066 627070 1×120 Flex 12,3 22,5 1415 331 135
629067 627072 1×150 Flex 14,7 25,0 1760 381 150
629068 627074 1×185 Flex 15,2 27,5 2095 429 165
629069 627076 1×240 Flex 18,2 30,5 2725 507 180
629070 627078 1×300 Flex 18,7 34,0 3365 582 205
628542 2×1,0 3,5 10,0 155 15 60
628602 2×1,5 3,8 11,0 175 20 65
628604 2×2,5 4,3 12,0 205 26 70
628606 2×4 4,9 13,0 280 34 80
628608 2×6 5,4 14,5 405 44 85
628610 2×10 8,7 17,0 600 61 100
629071 2×16 Flex 10,0 19,5 770 80 115
629072 2×25 Flex 14,5 24,0 1215 105 145
629073 2×35 Flex 14,7 26,0 1460 130 155
629074 2×50 Flex 18,1 30,0 1950 167 180
629075 2×70 Flex 18,7 34,0 2645 204 205
629076 2×95 Flex 22,2 37,5 3315 241 225
628543 628544 3×1,0 4,1 10,5 155 13 65
628622 628623 3×1,5 4,1 11,5 180 16 70
628624 628625 3×2,5 4,6 12,5 220 21 75
628626 628627 3×4 5,2 14,0 295 28 85
628628 628629 3×6 5,8 15,0 420 36 90
628630 628631 3×10 9,3 18,0 625 50 110
629082 629083 3×16 Flex 10,7 20,5 905 66 125
629084 629085 3×25 Flex 14,6 25,5 1385 86 155
629086 629087 3×35 Flex 15,0 27,5 1710 107 165
629088 629089 3×50 Flex 18,3 32,0 2355 137 195
629090 629091 3×70 Flex 22,0 36,5 3190 168 220
629092 629093 3×95 Flex 22,8 40,5 4025 199 240
629094 629095 3×120 Flex 37,8 45,5 5170 232 270
629096 629097 3×150 Flex 39,3 51,5 6415 267 310
629098 629099 3×185 Flex 43,4 56,5 7770 300 340
629100 629101 3×240 Flex 49,1 63,5 10135 355 380
628545 628546 4×1,0 4,1 11,5 180 13 70
628642 628643 4×1,5 4,5 12,5 215 16 75
628644 628645 4×2,5 5,0 14,0 275 21 85
628646 628647 4×4 5,8 15,0 360 28 90
628648 628649 4×6 8,8 17,0 535 36 100
628650 628651 4×10 10,3 20,0 760 50 120
629104 629105 4×16 Flex 11,9 23,0 1040 66 135
629106 629107 4×25 Flex 14,8 28,5 1550 86 170
629108 629109 4×35 Flex 18,1 30,5 1995 107 185
629110 629111 4×50 Flex 19,5 35,5 2715 137 210
629112 629113 4×70 Flex 22,4 40,5 3690 168 245
629114 629115 4×95 Flex 37,8 45,5 4860 199 270
629116 629117 4×120 Flex 39,3 50,5 6020 232 300
628547 628548 5×1,0 4,5 12,5 210 10 75
628662 628663 5×1,5 5,0 14,0 255 13 85
628664 628665 5×2,5 5,6 15,0 320 17 90
628705 628706 5×4 8,6 17,0 455 23 100
628707 628708 5×6 9,7 18,5 620 30 110
628709 628710 5×10 11,5 21,5 895 42 130
629126 629127 5×16 Flex 13,2 25,0 1230 55 150
629128 629129 5×25 Flex 18,1 31,0 1870 71 185
629130 629131 5×35 Flex 18,6 33,5 2415 89 200
629132 629133 5×50 Flex 21,6 39,0 3325 114 235
628549 628550 7×1,0 4,9 13,5 260 9 80
628551 628552 10×1,0 8,7 17,5 380 8 105
628553 628554 12×1,0 9,0 18,0 425 8 105
628555 628556 14×1,0 11,4 18,5 490 7 110
628557 628558 16×1,0 11,4 20,0 545 7 120
628559 628560 19×1,0 11,4 21,0 605 7 125
628561 628562 24×1,0 12,5 24,5 755 6 145
628563 628564 27×1,0 12,8 25,0 815 6 150
628564 30×1,0 13,3 26,0 885 5 155
628565 628566 37×1,0 14,4 28,0 1050 5 170
628666 628667 7×1,5 5,4 15,0 310 12 90
628723 628724 10×1,5 9,6 19,0 460 11 115
628670 628671 12×1,5 9,9 20,0 525 10 120
628727 628728 14×1,5 11,4 21,0 595 10 125
628731 628732 16×1,5 11,5 22,0 650 9 130
628674 628675 19×1,5 11,7 23,0 730 9 135
628678 628679 24×1,5 13,9 27,0 940 8 165
628682 628683 27×1,5 14,1 27,5 1015 8 165
30×1,5 14,7 28,5 1105 7 170
628684 628685 37×1,5 16,0 31,0 1315 7 185
628668 628669 7×2,5 8,5 16,5 430 16 100
628725 628726 10×2,5 11,5 21,0 600 14 125
628672 628673 12×2,6 11,5 21,5 675 13 130
628729 628730 14×2,5 11,8 23,0 780 13 140
628733 628734 16×2,5 12,5 24,5 865 12 145
628676 628677 19×2,5 13,2 25,5 980 11 155
628680 628681 24×2,5 15,7 30,0 1240 10 180
628686 628687 27×2,5 16,1 30,5 1350 10 185
30×2,5 16,7 32,0 1470 10 190
628688 628689 37×2,5 18,1 34,5 1775 9 205

G-type is with yellow/green earth conductor and marking on sheath is, for example, 3G1,5

Part number for oil resistant SHF2 cable:
4 + code from above table ➞ 4xxxxx
