LKSM-EMC-FRHF
Fire-resistant armoured power and control cable with improved EMC screening 0,6/1kV
Application: For fixed installation in most areas and on open deck in ships and off shore units. If the cable is exposed to direct sun light protective covering or cable with black outer sheath is recommended. Design to meet requirements for improved EMC screening properties.
| Main characteristics | |
| Rated voltage | AC 0,6/1kV (1,2kV) DC 0,9/1,5kV (if voltage to earth does not exceed 0,9kV) |
| Flame-retardant | IEC 60332-1-2 -test for single insulated wire and cable IEC 60332-3-22 -test for bunched wires and cables, category A |
| Fire-resistant | IEC 60331-1 and IEC 60331-2 |
| Halogen-free | IEC 60754 series |
| Smoke emission | IEC 61034 series |
| Oil resistance (only SHF2) | IEC 60811-404 conditions according to 60092-360/SHF2 |
| Transfer impedance | IEC 61196-1 (typical value 26dB over 1mΩ/m at 100MHz [20mΩ/m]) |
| Temperature rating: | Maximum conductor temperature + 90 °C Fixed installation -40 °C to +80 °C Minimum recommended installation temperature -15 °C |
| For details see general information section | |
| Part number Normal |
G-type | Number of conductors & cross-section n x mm2 |
Cross-section of armour mm2 |
Diameter of screen mm |
Nominal outer diameter mm |
Approximate weight kg/km |
Current Rating A at +45°C |
Min. bending radius fixed installation mm |
| – | – | 1×1,0 | 3,0 | 4,5 | 6,5 | 90 | 18 | 40 |
| – | – | 1×1,5 | 3,0 | 4,5 | 7,0 | 100 | 23 | 40 |
| – | – | 1×2,5 | 3,1 | 5,0 | 7,5 | 110 | 30 | 45 |
| – | – | 1×4 | 3,1 | 5,5 | 8,0 | 130 | 40 | 45 |
| – | – | 1×6 | 3,1 | 6,0 | 8,5 | 155 | 52 | 50 |
| – | – | 1×10 | 3,5 | 7,0 | 10,0 | 215 | 72 | 60 |
| – | – | 1×16 Flex | 4,1 | 8,5 | 11,0 | 285 | 94 | 65 |
| – | – | 1×25 Flex | 4,8 | 10,5 | 13,0 | 410 | 123 | 80 |
| – | – | 1×35 Flex | 5,5 | 11,5 | 14,0 | 515 | 153 | 85 |
| – | – | 1×50 Flex | 8,6 | 13,5 | 17,0 | 705 | 196 | 100 |
| – | – | 1×70 Flex | 10,0 | 15,5 | 18,5 | 935 | 240 | 110 |
| – | – | 1×95 Flex | 11,5 | 18,0 | 21,5 | 1190 | 284 | 130 |
| – | – | 1×120 Flex | 12,3 | 20,0 | 23,5 | 1465 | 331 | 140 |
| – | – | 1×150 Flex | 14,7 | 22,5 | 26,5 | 1800 | 381 | 160 |
| – | – | 1×185 Flex | 15,2 | 25,5 | 29,0 | 2165 | 429 | 175 |
| – | – | 1×240 Flex | 16,9 | 28,5 | 32,5 | 2790 | 507 | 195 |
| – | – | 1×300 Flex | 18,6 | 31,0 | 35,5 | 3420 | 582 | 210 |
| – | – | 2×1,0 | 3,7 | 7,5 | 10,0 | 140 | 15 | 60 |
| 27872 | – | 2×1,5 | 4,1 | 8,0 | 10,5 | 160 | 20 | 65 |
| 27873 | – | 2×2,5 | 4,5 | 9,0 | 11,5 | 190 | 26 | 70 |
| 27874 | – | 2×4 | 5,1 | 10,0 | 13,0 | 245 | 34 | 75 |
| 27875 | – | 2×6 | 5,6 | 11,0 | 14,0 | 365 | 44 | 85 |
| 27876 | – | 2×10 | 8,9 | 13,5 | 16,5 | 540 | 61 | 100 |
| 27877 | – | 2×16 Flex | 11,4 | 15,5 | 19,0 | 730 | 80 | 115 |
| 27878 | – | 2×25 Flex | 12,6 | 19,5 | 23,5 | 1070 | 105 | 140 |
| 27879 | – | 2×35 Flex | 14,8 | 22,0 | 25,5 | 1350 | 130 | 155 |
| 27880 | – | 2×50 Flex | 16,6 | 26,0 | 30,0 | 1815 | 167 | 180 |
| 27881 | – | 2×70 Flex | 19,0 | 30,0 | 34,5 | 2420 | 204 | 205 |
| – | – | 2×95 Flex | 21,5 | 35,0 | 39,5 | 3150 | 241 | 240 |
| – | – | 3×1,0 | 4,0 | 8,0 | 10,5 | 170 | 13 | 65 |
| 27882 | 28444 | 3×1,5 | 4,3 | 8,5 | 11,0 | 190 | 16 | 65 |
| 27883 | 28445 | 3×2,5 | 4,8 | 9,5 | 12,5 | 240 | 21 | 75 |
| 27884 | 28446 | 3×4 | 5,5 | 10,5 | 13,5 | 305 | 28 | 80 |
| 27885 | 28447 | 3×6 | 11,3 | 12,5 | 15,5 | 485 | 36 | 90 |
| 27886 | 28448 | 3×10 | 9,6 | 14,5 | 17,5 | 630 | 50 | 105 |
| 27887 | 28449 | 3×16 Flex | 11,5 | 17,5 | 20,5 | 890 | 66 | 125 |
| 27888 | 28450 | 3×25 Flex | 14,7 | 21,5 | 25,5 | 1315 | 86 | 155 |
| 27889 | 28451 | 3×35 Flex | 15,8 | 24,0 | 28,0 | 1675 | 107 | 170 |
| 27890 | 28452 | 3×50 Flex | 18,5 | 28,5 | 33,0 | 2280 | 137 | 200 |
| 27891 | 28453 | 3×70 Flex | 22,2 | 32,5 | 37,5 | 3055 | 168 | 225 |
| 27892 | 28454 | 3×95 Flex | 32,5 | 38,5 | 43,5 | 4055 | 199 | 260 |
| 27893 | 28455 | 3×120 Flex | 36,1 | 42,5 | 48,0 | 4980 | 232 | 290 |
| 27894 | 28456 | 3×150 Flex | 40,2 | 48,0 | 54,0 | 6200 | 267 | 325 |
| – | – | 4×1,0 | 4,4 | 9,0 | 11,5 | 195 | 13 | 70 |
| 27897 | 28459 | 4×1,5 | 4,8 | 9,5 | 12,5 | 230 | 16 | 75 |
| 27898 | 28460 | 4×2,5 | 5,4 | 10,5 | 13,5 | 280 | 21 | 80 |
| 27899 | 28461 | 4×4 | 11,3 | 12,0 | 15,0 | 420 | 28 | 90 |
| 27900 | 28462 | 4×6 | 9,2 | 13,5 | 16,5 | 540 | 36 | 100 |
| 27905 | 28463 | 4×10 | 10,7 | 16,0 | 19,5 | 760 | 50 | 115 |
| 27906 | 28464 | 4×16 Flex | 12,8 | 19,0 | 23,0 | 1095 | 66 | 135 |
| 27907 | 28465 | 4×25 Flex | 15,6 | 24,0 | 28,0 | 1595 | 86 | 165 |
| 27908 | 28466 | 4×35 Flex | 18,3 | 26,5 | 31,0 | 2090 | 107 | 185 |
| 27909 | 28467 | 4×50 Flex | 20,4 | 32,0 | 36,5 | 2825 | 137 | 220 |
| 27910 | 28468 | 4×70 Flex | 23,3 | 36,5 | 41,5 | 3840 | 168 | 250 |
| 27912 | 28469 | 4×95 Flex | 36,1 | 43,0 | 48,5 | 5055 | 199 | 290 |
| 27913 | 28470 | 4×120 Flex | 40,2 | 47,5 | 53,5 | 6285 | 232 | 320 |
| – | – | 4×150 Flex | 44,8 | 53,5 | 60,5 | 7820 | 267 | 360 |
| – | – | 5×1,0 | 4,9 | 9,5 | 12,5 | 235 | 10 | 75 |
| 27914 | 28471 | 5×1,5 | 5,3 | 10,5 | 13,0 | 270 | 13 | 80 |
| 27915 | 28472 | 5×2,5 | 6,0 | 11,5 | 14,5 | 335 | 17 | 85 |
| 27916 | 28473 | 5×4 | 11,3 | 13,5 | 16,5 | 490 | 23 | 100 |
| 27917 | 28474 | 5×6 | 11,4 | 15,0 | 18,0 | 660 | 30 | 110 |
| 27918 | 28475 | 5×10 | 11,9 | 18,0 | 21,5 | 940 | 42 | 130 |
| 27919 | 28476 | 5×16 Flex | 14,1 | 21,0 | 25,0 | 1325 | 55 | 150 |
| 27920 | 28477 | 5×25 Flex | 17,2 | 26,5 | 30,5 | 1940 | 71 | 185 |
| – | – | 7×1,0 | 5,4 | 10,5 | 13,5 | 270 | 9 | 80 |
| – | – | 10×1,0 | 9,6 | 14,0 | 17,0 | 400 | 8 | 105 |
| – | – | 12×1,0 | 10,0 | 14,5 | 18,0 | 445 | 8 | 105 |
| – | – | 14×1,0 | 10,5 | 15,5 | 18,5 | 495 | 7 | 110 |
| – | – | 16×1,0 | 11,1 | 16,5 | 19,5 | 540 | 7 | 115 |
| – | – | 19×1,0 | 11,8 | 17,0 | 20,5 | 630 | 7 | 125 |
| – | – | 24×1,0 | 13,9 | 20,5 | 24,0 | 815 | 6 | 145 |
| – | – | 27×1,0 | 14,4 | 21,0 | 24,5 | 870 | 6 | 150 |
| – | – | 30×1,0 | 14,9 | 21,5 | 25,5 | 935 | 6 | 155 |
| – | – | 37×1,0 | 16,2 | 23,5 | 27,5 | 1090 | 5 | 165 |
| 27921 | 28478 | 7×1,5 | 5,9 | 11,5 | 14,5 | 315 | 12 | 85 |
| 27923 | 28480 | 10×1,5 | 10,5 | 15,0 | 18,5 | 475 | 11 | 110 |
| 27925 | 28482 | 12×1,5 | 10,9 | 15,5 | 19,0 | 525 | 10 | 115 |
| 27927 | 28484 | 14×1,5 | 11,5 | 16,5 | 20,0 | 585 | 10 | 120 |
| 27929 | 28486 | 16×1,5 | 12,2 | 17,5 | 21,0 | 665 | 9 | 125 |
| 27931 | 28488 | 19×1,5 | 12,9 | 18,5 | 22,0 | 780 | 9 | 135 |
| 27933 | 28490 | 24×1,5 | 15,3 | 22,0 | 26,0 | 975 | 8 | 155 |
| 27935 | 28492 | 27×1,5 | 15,8 | 22,5 | 26,5 | 1055 | 8 | 160 |
| – | – | 30×1,5 | 16,4 | 23,5 | 27,5 | 1135 | 7 | 165 |
| 27937 | 28494 | 37×1,5 | 17,8 | 25,5 | 30,0 | 1345 | 7 | 180 |
| 27922 | 28479 | 7×2,5 | 9,9 | 13,0 | 16,0 | 445 | 16 | 95 |
| 27924 | 28481 | 10×2,5 | 11,7 | 17,0 | 20,0 | 605 | 14 | 120 |
| 27926 | 28483 | 12×2,5 | 12,1 | 17,5 | 21,0 | 700 | 13 | 125 |
| 27928 | 28485 | 14×2,5 | 12,8 | 18,5 | 22,0 | 780 | 12 | 135 |
| 27930 | 28487 | 16×2,5 | 13,6 | 19,5 | 23,5 | 860 | 12 | 140 |
| 27932 | 28489 | 19×2,5 | 14,4 | 21,0 | 24,5 | 1020 | 11 | 150 |
| 27934 | 28491 | 24×2,5 | 17,2 | 24,5 | 28,5 | 1280 | 10 | 170 |
| 27936 | 28493 | 27×2,5 | 17,6 | 25,5 | 29,5 | 1410 | 10 | 180 |
| – | – | 30×2,5 | 18,3 | 26,5 | 30,5 | 1525 | 10 | 185 |
| 27938 | 28495 | 37×2,5 | 20,0 | 28,5 | 33,0 | 1790 | 9 | 200 |
Other sizes on request.
Part number for oil resistant SHF2 cable:
4 + code from above table ➞ 4xxxxx
